Pipe Fitting Material
Malleable Iron
Specific Fitting Shape
Hex Bushing
Fitting Schedule/Class
Class 150
Pipe Size - Pipe Fitting
3/8 in x 1/4 in
Basic Pipe Fitting Material
Metal
Fitting Connection Type
FNPT x MNPT
Basic Pipe Fitting Shape
Bushing
Standards
UL: FM Approved: ASME B16.3
Specific Pipe Fitting Shape
Hex Bushing
Max. Pressure
300 psi@150 Degrees F
Pipe Fitting Schedule/Class
Class 150
Pipe Fitting Connection Type
Male NPT x Female NPT
Saturated Steam Pressure
150 psi @ 350 Degrees F
Temp. Range
-20 Degrees to 350 Degrees F
Pressure Level
High Pressure (1000-3000 psi)
Maximum Operating Pressure
2,000 psi @ 150 Degrees F
Pipe Fitting Gender
Male Female
Includes Pre-Applied Thread Sealant
No
Fitting Side A Nominal Pipe Size
3/8 in
Class/Pressure
Class 300 2,000 psi @ 150 Degrees F
Application
Air, Natural Gas, Non-Potable Water, Oil, Steam
Fitting Side B Gender
Female
Fitting Side B Nominal Pipe Size
1/4 in
Fitting Side A Gender
Male
Country of Origin (subject to change)
United States
