Pipe Size - Valves
1 1/2 in
Center Line Pipe Center Size
4 3/16 in
Electrical Connections
1/2
Valve Design
2-Way/2-Position
Valve Configuration
Normally Closed
Body Material - Valves
Brass
Environmental Rating - Valves
Indoor, Outdoor
Max. Fluid Temp.
180 Degrees F
Application
Air Compressors, Car Wash, Industrial Water Control, Laundry Equipment, Pumps
Valve Ways and Positions
2-Way/2-Position
Seal Material - Valves
NBR
Max. Operating Pressure Differential Water
150 psi
Max. Operating Pressure Differential Light Oil
100 psi
Coefficient of Volume
22.5
NEMA Rating
1, 2, 3, 3S, 4, 4X
Min. Operating Pressure Differential
5 psi
Media
Air/Inert Gas, Light Oil and Water
Max. Operating Pressure Differential Air/Inert Gas
150 psi
Coil Enclosure
Watertight No Junction Box
Operation Type
Pilot Operated
Operating Pressure Differential Water - Maximum
150 psi
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Nominal Pipe Size
1 1/2 in
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
NEMA Enclosure Rating
1, 2, 3, 3S, 4, 4X
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Ambient Temperature - Maximum
140 Degrees F
Outlet Connection Type
NPTF
Operating Pressure Differential Steam - Minimum
Not Applicable
Operating Pressure Differential Light Oil - Maximum
100 psi
Coefficient of Volume (Cv)
22.5
Ambient Temperature - Minimum
14 Degrees F
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Minimum
5 psi
Valve Starting Configuration
Normally Closed
Operating Pressure Differential - Minimum
5 psi
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
Operating Pressure Differential Hot Water - Minimum
Not Applicable
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
Environmental Rating
Indoor, Outdoor
Inlet Connection Type
NPTF
Operating Pressure Differential Steam - Maximum
Not Rated
Mounting Orientation
Vertical
Fluid Temperature - Maximum
180 Degrees F
Valve Positions
2-Position
Operating Pressure Differential Light Oil - Minimum
5 psi
Operating Pressure Differential - Maximum
150 psi
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
For Media
Air, Inert Gases, Light Oil, Water
Operating Pressure Differential Air/Inert Gas - Maximum
150 psi
Operating Pressure Differential Water - Minimum
5 psi
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Operating Pressure Differential Hot Water - Maximum
Not Rated
Products By Industry
Food Processing;General Approach
Country of Origin (subject to change)
Mexico
