Application
Air, Non-Potable Water, Steam
Fitting Connection Type
Tube x Tube
Specific Fitting Shape
Tee
Tube Fitting Material
316 Stainless Steel
Specific Pipe Fitting Shape
Adapter
Basic Pipe Fitting Shape
Tee
Pipe Fitting Connection Type
Tube x Tube
Basic Pipe Fitting Material
Metal
Temp. Range
23 Degrees to 302 Degrees F
Overall Length
42 13/16 mm
Connection Type
Push-to-Connect x Push-to-Connect x Push-to-Connect
Fitting Side A Tube Outer Diameter
3/8 in
Maximum Operating Temperature
302 Degrees F
System of Measurement
Imperial
Compatible Tube Material
FEP, Nylon, PFA, Polyolefin, Polyurethane, Soft Nylon
Maximum Operating Pressure
145 psi
Fitting Side C Connection Type
Push-to-Connect
Includes Pre-Applied Thread Sealant
No
Fitting Side B Connection Type
Push-to-Connect
Release Ring Material
Stainless Steel
Fitting Side A Connection Type
Push-to-Connect
Fitting Side B Tube Outer Diameter
3/8 in
Fitting Material
Stainless Steel
Fitting Side C Tube Outer Diameter
3/8 in
Minimum Operating Temperature
41 Degrees F
Fitting Body Material
316 Stainless Steel
For Tube Outside Diameter
3/8 in
End Connection Type
Push-to-Connect
For Tube OD
3/8 in x 3/8 in x 3/8 in
Country of Origin (subject to change)
Japan
