Connection Type
Socket x Thread
Temp. Range
0 Degrees to 160 Degrees F
Features
Lockout/Tagout Directly to Body, Integral Mounting, Double O-Ring Stem Seals, Reversible Seats, System2TM Sealing Technology
Handle Material
Glass Filled Polypropylene
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Special Features
Actuator Compatible
General Connection Type
Socket
For Media
Corrosive Chemicals, Water
Vacuum Service Rating
Not Rated
Coefficient of Volume (Cv)
150
Valve Construction
Three-Piece
Connection Type - Side 2
Socket
NSF Certifications for Food and Drinking Water
NSF 61
Included Mounting
ISO 5211 Actuator Mounting Pad
Connection Type - Side 1
True-Union Socket/True-Union NPT
Connection Size - Side 2
2 in
Connection Gender - Side 2
Female
Operating Temperature - Maximum
190 Degrees F
Connection Gender - Side 1
Female
Pipe Schedule Compatibility
Not Applicable
Vented Ball Valve
Non-Vented
Maximum Pressure - Steam
Not Applicable
Maximum Pressure - Operating
250 psi
Connection Size - Side 1
2 in
Maximum Pressure - Combustible Gas
Not Rated
3-A Standard Compliance
Not Rated
Manufacturer Warranty
3 yr
Average Surface Roughness (Ra)
Not Applicable
Operating Temperature - Minimum
34 Degrees F
ANSI Flange Class
Not Applicable
Country of Origin (subject to change)
United States
