Features
Double O-Ring Stem Seals, Integral Mounting, Lockout/Tagout Directly to Body, Reversible Seats, System2TM Sealing Technology
Handle Material
Glass Filled Polypropylene
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Connection Type
Socket x Thread
Temp. Range
0 Degrees to 140 Degrees F
Special Features
Actuator Compatible
General Connection Type
Socket
Vacuum Service Rating
Not Rated
Average Surface Roughness (Ra)
Not Applicable
Operating Temperature - Minimum
34 Degrees F
NSF Certifications for Food and Drinking Water
NSF 61
Coefficient of Volume (Cv)
16
Maximum Pressure - Operating
250 psi
Connection Size - Side 1
3/4 in
Connection Gender - Side 1
Female
Vented Ball Valve
Non-Vented
Maximum Pressure - Combustible Gas
Not Rated
Operating Temperature - Maximum
140 Degrees F
Maximum Pressure - Steam
Not Applicable
Valve Construction
Three-Piece
Included Mounting
ISO 5211 Actuator Mounting Pad
Connection Type - Side 2
Socket
ANSI Flange Class
Not Applicable
Manufacturer Warranty
3 yr
Connection Gender - Side 2
Female
3-A Standard Compliance
Not Rated
Connection Type - Side 1
True-Union Socket/True-Union NPT
Connection Size - Side 2
3/4 in
For Media
Corrosive Chemicals, Water
Pipe Schedule Compatibility
Not Applicable
Country of Origin (subject to change)
United States
