| Property | Value |
|---|---|
| Item | Indexable Face Mill |
| Depth of Cut | 6.00mm |
| Overall Length | 63.00mm |
| Cutting Direction | Right Hand |
| Insert Size | 1205 |
| Features | Double-Sided 10-Edge Inserts, Fine Pitch, Reduced Chattering with Low Cutting Forces Due to Curved Cutting Edge Design, Suppresses Fracturing with Dual Angle Edge Design |
| ANSI Code | MFPN45160R12T |
| Arbor Dia. | 2 in |
| Hub Outside Dia. | 173.00mm |
| Cutting Application | Chamfering, Face Milling |
| Insert Style | PNEU; PNMU |
| Rake | -6 Degrees Radial, 10 Degrees Axial |
| ISO Number | MFPN45160R-12T |
| Min. Cutting Dia. | 160.00mm |
| Side Cutting Edge Angle | 45 Degrees |
| Max. Cutting Dia. | 173.00mm |
| Number of Inserts | 12 |
| Insert Holding Type | Screw |
| Coolant Fed | Non-Coolant Through |
| Country of Origin (subject to change) | Japan |
| Package Quantity | 1 |
Face Mill, MFPN 45160R12T, MFPN 160.00mm Cutting Dia, Kyocera, Mfr#: MFPN45160R12T
$1275.99
Free shipping will be applied on orders over $50
Indexable Face Mill, Max. Cutting Dia. 173.00mm, Arbor Dia. 2 in, Depth of Cut 6.00mm, ANSI Code MFPN45160R12T, Coolant Fed Non-Coolant Through, Cutting Application Chamfering, Face Milling
9999 in stock
