Pipe Fitting Material
Brass, Malleable Iron
Fitting Connection Type
FIP x Solder
Pipe Size - Pipe Fitting
2
Standards
ANSI B16.42; Federal Specifications for Tensile Strength and Thread End Connections
Insulator Material
Polysulfone
Pipe Fitting Connection Type
FIP x Solder
Basic Pipe Fitting Material
Metal
Basic Pipe Fitting Shape
Flange
Specific Fitting Shape
Dielectric Flange
Fitting Side B Material
Gray Cast Iron
Fitting Side A Material
Brass
Fitting Pipe Size
2 in x 2 in
Fitting Side A Nominal Pipe Size
2 in
Fitting Side A Flange Thickness
3 1/4 in
Fitting Side A Flange Diameter
5 1/8 in
Dielectric Flange Diameter
5 1/8 in
Low Lead Compliance Level
Compliant
Fitting Side B Class
Class 125
Maximum Operating Pressure
250 psi
Fitting Material
Brass, Iron
Dielectric Union Lead Free Designation
Lead-Free
Connection Type
Solder, Threaded
Fitting Side B Type
Solder
Fitting Side B Finish/Coating
Zinc-Plated Galvanized
Fitting Side A Gender
Female
Fitting Material Type
Lead-Free Brass x Zinc-Plated Galvanized Gray Cast Iron
Application
Air, Alkalines, Gasoline, Mineral Oil, Natural Gas, Non-Potable Water, Oil, Propane, Vegetable Oil
Fitting Side B Nominal Pipe Size
2 in
Pipe Fitting Gender
Female
Country of Origin (subject to change)
United States
