For Pipe Size
1/2 in, 1/4 in, 2 in, 3/8 in
Wetted Materials
301 Stainless Steel, 302 Stainless Steel, Brass, Ceramic
For Use With
Liquids or Gases
Min. Fluid Temp. (F)
-4 Degrees F
Standards
ATEX, CE Certified, CSA Certified, IECEx, KTL, UL Listed
Max. Pressure (PSI)
1,000 psi
Material of Construction
Brass
Min. Ambient Temp. (F)
-4 Degrees
Connection Size (In.)
1/2 MNPT
Max. Fluid Temp. (F)
220 Degrees F
Contact Rating
5A at 125/250V AC
Application
Coolant Loops, Other
Max. Ambient Temp. (F)
167 Degrees F
Filter Rating - Maximum
Not Applicable
Flow Rate - Maximum
Not Applicable
Ambient Temperature - Maximum
167 Degrees F
Wetted Material
301 Stainless Steel, 302 Stainless Steel, 303 Stainless Steel, 304 Stainless Steel, Brass, Cast Iron, Ceramic, Steel
Set Point Configuration
Adjustable
Media Temperature - Minimum
-4 Degrees F
Ambient Temperature - Minimum
-4 Degrees F
Contact Rating (DC)
30 A (Inductive) @ 30V (CSA, ATEX and IECEx Models), 5 A Resistive @ 30V (CSA, ATEX and IECEx Models)
Media Temperature - Maximum
220 Degrees F
Contact Rating (AC)
5 A @ 125/250V
Nameplate Voltage
Not Applicable
Switch Position
Normally Closed, Normally Open
Hazardous Location Specification
Class I, Div 1 and 2, Group A, B, C, D, Class II, Div 1 and 2, Group E, F, G
Flow Rate - Minimum
Not Applicable
Country of Origin (subject to change)
United States
