Specific Fitting Shape
Straight Adapter
Tube Fitting Material
Brass
Basic Pipe Fitting Shape
Adapter
Specific Pipe Fitting Shape
Adapter
Connection Type
Push-to-Connect x MNPT
Basic Pipe Fitting Material
Metal
Temp. Range
0 Degrees to 160 Degrees F
Fittings Sub-Category
Adapters
Body Material
Nickel Plated Brass
Pipe Fitting Connection Type
MNPT x Tube
Pipe Size - Pipe Fitting
1/2 in
Standards
ISO 14743:2004, PED 2014/68/UE, REACH 1907/2006, RoHS 2011/65/CE, Silicone Free Certified
Compatible Tube Material
Copper, Nylon, Polyethylene, Polyurethane
Maximum Operating Pressure
290 psi
System of Measurement
Imperial
Includes Pre-Applied Thread Sealant
Yes
Fitting Side B Pipe Size
1/2 in
Maximum Operating Temperature
160 Degrees F
Minimum Operating Temperature
0 Degrees F
Finish/Coating
Nickel Plated
Fitting Side A Connection Type
Push-to-Connect
Fitting Thread Size
1/2-14
Fitting Side A Tube Outer Diameter
1/2 in
Fitting Side B Connection Type
MNPT
End Connection Type
Push-to-Connect, Threaded
For Tube Outside Diameter
1/2 in
Fitting Body Material
Nickel Plated Brass
Country of Origin (subject to change)
Italy
