Action
Maintained/Maintained
NEMA Rating
1, 12, 2, 3, 3R, 4, 4X
Lamp Type
No Lamp Module Included
Operator Head Material
Plastic
Contact Rating
10A @ 600V AC, 1A @ 600V DC
IP Rating
IP20, IP66, IP67, IP69, IP69K
Switch Operation @ Position A
XO
Switch Operation @ Position D
No Fourth Position
Switch Operation @ Position C
No Third Position
NEMA Contact Rating Designation
A600/R300
Switch Operation @ Position B
OX
Standards
REACH Art. 33, RoHS, WEEE (2012/19/EU)
Lamp Module Type
No Lamp Module Included
AC Contact Rating
10 A @ 600 V
DC Contact Rating
1 A @ 600 V
Switching function latching
Yes
Number of switch positions
2
Type of control element
Toggle
Number of contacts as normally open contact
1
Degree of protection (IP)
IP67/IP69K
Type of electric connection
Screw connection
Number of contacts as normally closed contact
1
Suitable for illumination
Yes
Number of contacts as change-over contact
0
Operator Head Color
Black/White
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4, 4X
Includes Operator Key
Not Applicable
Contact Block Material
Metal
Switch Function @ 3rd Position
No Third Position
Key Removal Position
Not Applicable
Lamp Voltage - Maximum
Not Applicable
Switch Function @ 4th Position
No Fourth Position
Metal Operator Head Finish
Not Applicable
Switch Function @ 2nd Position
On
Switch Function @ 1st Position
Off
Hazardous Location Specification
Not Rated
Operator Head Type
Short-Handled Knob
Panel Cutout Diameter
22 mm
Operator Illumination
Illuminated
Country of Origin (subject to change)
Czechia
