Terminal Connection
Screw Clamp
Lamp Module Type
Full Voltage
IP Rating
IP66, IP67, IP69, IP69K
Lamp Voltage
110 to 120 V AC
Replacement Lamps
Integrated
Standards
CSA, REACH, RoHS, UL Listed, WEEE
Vibration Resistance
5 gn 12 to 500 Hz)IEC 60068-2-6
Light Source
Universal LED
Resistance To High Pressure Washer
1015.26 psi (7000000 Pa) 131°F (55°C) 0.1 m
Service Life
100000 h at rated voltage and 25°C
Bezel Material
Dark Gray plastic
Product Certifications
UL Listed; CSA
Shock Resistance
50 gn 18 ms) half sine wave acceleration IEC 60068-2-27; 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Resistance To Fast Transients
2 kV IEC 61000-4-4
Resistance To Electromagnetic Fields
9.14 V/m (10 V/m) IEC 61000-4-3
Surge Withstand
1 kV IEC 61000-4-5
Supply Voltage Limits
100 to 132 V AC
Overvoltage Category
Class II IEC 60536
NEMA Degree Of Protection
NEMA 13; NEMA 4X
Rated Impulse Withstand Voltage
4 kV IEC 60947-1
Rated Supply Voltage
110 to 120 V AC 50/60 Hz
Mounting Diameter
1.20 in (30.5 mm)
Resistance To Electrostatic Discharge
6 kV on contact (on metal parts) IEC 61000-4-2; 8 kV in free air (in insulating parts) IEC 61000-4-2
IP Degree Of Protection
IP66 IEC 60529; IP67 IEC 60529; IP69 IEC 60529; IP69K ISO 20653
Device Presentation
Complete product
Connections - Terminals
Screw clamp terminals, Less than or Equal to 2 x 1.5 mm² with cable end IEC 60947-1; Screw clamp terminals, 1 x 0.22 to 2 x 2.5 mm² without cable end IEC 60947-1
Electromagnetic Compatibility
Electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2; Electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2; Electromagnetic emission class B conforming to IEC 55011
IK Degree Of Protection
IK03 IEC 50102
Electromagnetic Emission
Class B IEC 55011
Ambient Air Temperature For Operation
-40 to 158°F (-40 to 70°C)
Rated Insulation Voltage
250 V 3)IEC 60947-1
Ambient Air Temperature For Storage
-40 to 158°F (-40 to 70°C)
Includes Lamp Module
Lamp Module Included
Resistance Properties
Dust Resistant, Shock Resistant, Waterproof
Lamp Voltage - Maximum
120 V AC
Includes Lens
Lens Included
NEMA Enclosure Rating
13, 4X
Includes Push-To-Test
No Push-To-Test Included
Panel Cutout Diameter
30 mm
Voltage Rating - Maximum
120 V AC
Country of Origin (subject to change)
France
