Body Material
Polypropylene
Body Style
Inline True Union
Temp. Range
32 Degrees to 176 Degrees F
Handle Material
Glass Filled Polypropylene
Stem Material
Polypropylene
Max. Steam Pressure
75 psi WSP
Ball Valve Basic Body Material
Plastic
Features
Integrated Stainless Steel Mounting Inserts
Connection Type
FNPT x FNPT
Ball Valve Product Group
Manual
Ball Material
Polypropylene
Type
Two Piece, True Union, Actuatable
Special Features
Actuator Compatible
General Connection Type
Female NPT
Material of Construction
Polypropylene
Sub-Category
Synthetic Ball Valves
Maximum Pressure - Operating
10 bar
Connection Gender - Side 2
Female
Valve Construction
Two-Piece
Pipe Schedule Compatibility
Not Applicable
Connection Type - Side 1
NPT
Maximum Pressure - Steam
Not Applicable
Operating Temperature - Minimum
32 Degrees F
Maximum Pressure - Combustible Gas
Not Rated
Color - Valve Handle
Orange
For Media
Corrosive Chemicals, Water
Connection Size - Side 1
1 in
Included Mounting
Base Pad
Coefficient of Volume (Cv)
49
Connection Size - Side 2
1 in
Average Surface Roughness (Ra)
Not Applicable
Connection Type - Side 2
NPT
Vacuum Service Rating
Not Applicable
Operating Temperature - Maximum
176 Degrees F
Vented Ball Valve
Not Applicable
3-A Standard Compliance
Not Rated
Handle - Locking
Not Applicable
Connection Gender - Side 1
Female
ANSI Flange Class
Not Applicable
NSF Certifications for Food and Drinking Water
NSF 61
Country of Origin (subject to change)
Switzerland
