Differential Pressure Gauge Type
Differential Pressure Gauge
Gauge Nominal Dial Size
2 1/2 in
Basic Gauge Case Material
Metal
Basic Gauge Wetted Parts
Stainless Steel / Buna-N
Differential Gauge Connection Type
FNPT
Differential Gauge Connection Size
1/4 in
Gauge Connection Location
Back
Differential Pressure Range Units
psi
Differential Pressure Range Value
0 to 20
Dial Material
Engineered Plastic
Manufacturers Warranty Length
5 yr
Rated Total Pressure
6,000 psi
Differential Pressure Range
0 to 20 psi
Body Material
316 Stainless Steel
Gauge Primary Range Smallest Graduation
1
Gauge Operating Temp. Range
-40 Degrees to 200 Degrees F
Item
Differential Pressure Gauge
Piston Material
Stainless Steel
Application - Max Pressure
For High Operating Pressure
Process Connection Gender
Female
Process Connection Location
Back
Housing Material
316L Stainless Steel
Max Pressure Application
For High Operating Pressure
IP/NEMA Rating
IP65, NEMA 4X
Process Connection Size
1/4 in
Panel Mount Characteristics
3 L Dia Holes on E Dia Bolt Circle
Movement Material
Stainless Steel
Process Connection Type
NPT
Brand and Series
MIDWEST INSTRUMENT 120
Pressure Gauge Type
Differential Pressure Gauge
Nominal Dial Size
2 1/2 in
Includes Mounting Hardware
No
Manufacturer Warranty Length
5 yr
Maximum Working Static Pressure
6,000 psig
Includes Calibration Certificate
No
Case Construction
Glass Reinforced
Bolt Circle Diameter
3.5 in
Process Connection
1/4 in NPT Female
Process Temperature Range
-40 Degrees to 200 Degrees F
Pressure Range
0 to 20 psid
Primary Scale Minor Graduations
1
Application
Compressors, Filtration Monitoring, Pressure Detection, Hydraulics, Flow Measurement, Pumps, Refrigeration, Valves
Gauge Case Material
Plastic
Accuracy Grade
ASME B40.1 Grade B
Ambient Operating Temperature Range
-40 Degrees to 200 Degrees F
Hazardous Location Rating
Not Rated
Bezel Gasket Material
Buna-N
Country of Origin (subject to change)
United States
