Connection Type
FNPT Union x FNPT
Material
Lead Free Bronze, Stainless Steel
Application
Commercial Use, Residential Use
Pressure Adjustment Range
75 to 125 psi
Standards
ASSE 1003, CSA B356, cUPC
Item
Pressure Reducing Valve
Compliance
ASSE(R) Listed 1003, CSA(R) Certified, IAPMO(R) Listed, NSF/ANSI 61 /CAN 61 u0026 372
Preset Pressure Settings
50 psi
Valve Type
High Range Pressure Reducing Valve
Factory Set Pressure
50 psi
Material - Valve
Lead Free Bronze, Stainless Steel
Outlet Connection Size
1 in
Pilot Adjustment - Maximum
125 psi
Inlet Connection Size
1 in
Operating Pressure - Minimum
60 psi
Flow Rate - Intermittent Maximum
Not Applicable
Includes Strainer
Strainer Not Included
Flow Rate - Continuous Maximum
42.3 gpm
Pilot Adjustment - Minimum
75 psi
Coating/Lining
NSF Listed Fusion Bonded Epoxy Lining and Coating
Operating Pressure - Maximum
400 psi
NSF Certifications for Food and Drinking Water
NSF 372, NSF 61
Outlet Connection Type
NPT
Inlet Connection Gender
Female
Outlet Connection Gender
Female
Fluid Temperature - Maximum
140 Degrees F
Country of Origin (subject to change)
China
