| Number of Columns | 1 |
| Item | Pushbutton Enclosure |
| Hole Size | 22 mm |
| Material | Mild steel |
| Number of Holes | 1 |
| Conduit Size | No Conduit Entrance Holes Provided |
| NEMA Rating | 12 |
| Dimensions | 4.00 in H x 4.00 in W x 4.75 in D |
| Height | 4 in |
| Width | 4 in |
| Depth | 4.75 in |
| Color | ANSI 61 Gray Polyester Powder |
| For Use With | All Standard Brands of 22mm Oil Tight Push Buttons, Switches and Pilot Lights |
| Includes | Captive Cover Screws, Closed Cell Oil Resistant Gasket, Grounding Stud |
| Mounting Style | External Feet |
| Standards | UL Type 12, 13, CSA, Nema, cUL, IP65 |
| Mounting (G x H) (inch) | 4.50 x 3.12 |
| Protection Rating | NEMA Type 12 |
| Thickness (T) (gauge) | 16 |
| Type Number | Type 13 |
| IP Rating | IP65 |
| Hole Size (millimetre) | 22.5 mm |
| Hole Quantity | 1 |
| Overall Dimensions (L x W) (inch) | 5.00 x 4.22 |
| Depth (D) (inch) | 4.75 |
| Modification Services | Yes |
| Size | 1PB x 22.5mm |
| Color Code | ANSI 61 |
| Finish | Powder Coated |
| Width (W) (inch) | 4 |
| Height (H) (inch) | 4 |
| Length | 5.00 inch |
| Thickness | 16 ga / 1.52 mm |
| Overall Dimensions | 5.00 x 4.22 in / 127 x 107 mm |
| Mounting | 4.50 x 3.12 in / 114 x 79 mm |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Pushbutton Enclosure, 4.00 in H, 4.75 in D, NVENT HOFFMAN, Mfr# E1PBXM
$124,16
Free shipping will be applied on orders over $50
Pushbutton Enclosure, Number of Columns 1, Number of Holes 1, NEMA Rating 12, Conduit Size No Conduit Entrance Holes Provided, Dimensions 4.00 in H x 4.00 in W x 4.75 in D, Hole Size 22 mm, Material Mild Steel, Height 4 in, Width 4 in, Depth 4.75 in, Color ANSI 61 Gray Polyester Powder, Includes Captive Cover Screws, Closed Cell Oil Resistant Gasket, Grounding Stud, For Use With All Standard Brands of 22mm Oil Tight Push Buttons, Switches and Pilot Lights, Mounting Style External Feet
9999 in stock
Must order in multiples of 1
Subtotal:
$124.16
