Item | Solenoid Air Control Valve |
Valve Ways and Positions | 5-Way/2-Position |
Voltage | 24V DC |
Valve Actuator / Return | Solenoid / Spring |
Coefficient of Volume | 0.61 |
Pipe Size | 1/8 in |
Max. CFM - Valves | 0.9 cfm |
Operational Pressure Range | 22 to 100 psi |
CFM | 0.9 |
Overall Length | 4 1/2 in |
Standards | CE |
Body Style | Manifold |
Shifting Technology | Solenoid |
Pilot Pressure | 22 |
Pressure Range | 22 to 100 psi |
Actuator/Return | Solenoid/Spring |
Overall Width | 2 in |
Overall Height | 1 in |
Air Valve Type | 5-Way, 2-Position |
Electrical Connections | DIN Terminal With Connector |
Pilot Port Size | 1/8 in NPTF |
Power Consumption | 0.45 W |
Ambient Temp. Range | 14 Degrees to 122 Degrees F |
Country of Origin (subject to change) | Japan |
Package Quantity | 1 |
Solenoid Air Control Valve, 1/8 In, 24VDC, SMC, Mfr# SY5120-5DZ-01T
$63.20
Free shipping will be applied on orders over $50
Solenoid Air Control Valve, Valve Ways and Positions 5-Way/2-Position, Voltage 24V DC, Valve Actuator / Return Solenoid / Spring, Pipe Size 1/8 in, Max. CFM - Valves 0.9 cfm, Operational Pressure Range 22 to 100 psi, Body Style Manifold, Pilot Port Size 1/8 in NPTF, Pilot Pressure 22, Coefficient of Volume 0.61, DIN Terminal With Connector Electrical Connections, Shifting Technology Solenoid, Power Consumption 0.45 W, Ambient Temp. Range 14 Degrees to 122 Degrees F, Overall Height 1 in
9999 in stock
Must order in multiples of 1
