Center Line Pipe Center Size
2 13/16 in
Electrical Connections
DIN
Valve Design
2-Way/2-Position
Valve Configuration
Normally Closed
Body Material - Valves
Brass
Environmental Rating - Valves
Indoor, Outdoor
Max. Operating Pressure Differential Air/Inert Gas
90 psi
Max. Fluid Temp.
180 Degrees F
Media
Air/Inert Gas, Light Oil and Water
Valve Ways and Positions
2-Way/2-Position
Coil Enclosure
Watertight No Junction Box
NEMA Rating
1, 2, 3, 3S, 4, 4X
Max. Operating Pressure Differential Light Oil
90 psi
Seal Material - Valves
NBR
Coefficient of Volume
0.88
Min. Operating Pressure Differential
0 psi
Max. Operating Pressure Differential Water
90 psi
Application
Boilers, Burners, Car Wash Equipment, Compressors, Dishwashing and Laundry Equipment, Food Processing and Many Others, Pumps
Operation Type
Direct Acting
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Environmental Rating
Corrosive, Hazardous, Indoor, Outdoor
Operating Pressure Differential Water - Maximum
90 psi
Operating Pressure Differential Air/Inert Gas - Maximum
90 psi
Operating Pressure Differential - Minimum
0 psi
Operating Pressure Differential Light Oil - Maximum
90 psi
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Minimum
0 psi
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Valve Starting Configuration
Normally Closed
Operating Pressure Differential Water - Minimum
0 psi
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Operating Pressure Differential Hot Water - Maximum
Not Rated
Inlet Connection Type
NPTF
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
For Media
Air, Inert Gases, Light Oil, Water
NEMA Enclosure Rating
1, 2, 3, 3S, 4, 4X
Fluid Temperature - Maximum
180 Degrees F
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
Operating Pressure Differential Steam - Minimum
Not Applicable
Ambient Temperature - Minimum
14 Degrees F
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
Mounting Orientation
Horizontal or Vertical
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Coefficient of Volume (Cv)
0.88
Operating Pressure Differential Steam - Maximum
Not Rated
Ambient Temperature - Maximum
140 Degrees F
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Light Oil - Minimum
0 psi
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
Valve Positions
2-Position
Outlet Connection Type
NPTF
Country of Origin (subject to change)
Mexico
