Center Line Pipe Center Size
2 9/16 in
Electrical Connections
1/2
Valve Design
4-Way/2-Position
Valve Configuration
Universal
Body Material - Valves
Brass
Max. Operating Pressure Differential Light Oil
125 psi
Valve Ways and Positions
4-Way/2-Position
Coil Enclosure
Explosionproof and Watertight
Min. Operating Pressure Differential
0 psi
Max. Operating Pressure Differential Water
125 psi
NEMA Rating
3, 3S, 4, 4X, 6, 6P, 7, 9
Seal Material - Valves
FKM
Media
Air/Inert Gas, Light Oil and Water
Max. Operating Pressure Differential Air/Inert Gas
125 psi
Max. Fluid Temp.
160 Degrees F
Environmental Rating - Valves
Explosion Proof, Indoor, Outdoor
Application
Analytical and Diagnostic Equipment, Biofuel and Heating Systems, Dust Collector Systems, Heating Equipment, Refining Applications
Operation Type
Direct Acting
Fluid Temperature - Maximum
160 Degrees F
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
NEMA Enclosure Rating
3, 3S, 4, 4X, 6, 6P, 7, 9
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Mounting Orientation
Horizontal or Vertical
For Media
Air, Inert Gases, Light Oil, Water
Inlet Connection Type
NPTF
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Coefficient of Volume (Cv)
0.7
Ambient Temperature - Minimum
32 Degrees F
Outlet Connection Type
NPTF
Operating Pressure Differential - Minimum
0 psi
Operating Pressure Differential Light Oil - Minimum
0 psi
Operating Pressure Differential Light Oil - Maximum
125 psi
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Minimum
0 psi
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
Operating Pressure Differential Hot Water - Maximum
Not Rated
Operating Pressure Differential Air/Inert Gas - Maximum
125 psi
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
Valve Positions
2-Position
Operating Pressure Differential Water - Maximum
125 psi
Operating Pressure Differential Steam - Minimum
Not Applicable
Environmental Rating
Indoor, Outdoor
Operating Pressure Differential Water - Minimum
0 psi
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Operating Pressure Differential Steam - Maximum
Not Rated
Ambient Temperature - Maximum
125 Degrees F
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
Country of Origin (subject to change)
Mexico
