Specific Pipe Fitting Shape
Gauge
Fitting Connection Type
Push-Fit
Special Features
Connects Copper, Pex and CPVC in any Combination without the Use of Soldering, Unions or Glue, Temperature Gauge
Compliance
ASSE 1061/NSF61, NSF/ANSI 372
Tube Fitting Material
DZR Brass
Basic Pipe Fitting Material
Metal
Basic Pipe Fitting Shape
Tee
Pipe Size - Pipe Fitting
1/2 in
Specific Fitting Shape
Temperature Gauge Tee
Temp. Range
0 Degrees to 250 Degrees F
Standards
ASSE 1061, NSF/ANSI 61
Pipe Fitting Connection Type
Push-Fit
Connection Type
Push-to-Connect x Push-to-Connect
Fitting Side A Connection Type
Push-to-Connect
Minimum Operating Temperature
0 Degrees F
Release Ring Material
EPDM
System of Measurement
Imperial
Maximum Operating Temperature
250 Degrees F
Resistance Properties
Corrosion-Resistant
Includes Pre-Applied Thread Sealant
No
Fitting Side B Connection Type
Push-to-Connect
Fitting Side B Tube Outer Diameter
1/2 in
Maximum Operating Pressure
200 psi
Fitting Side A Tube Outer Diameter
1/2 in
Compatible Tube Material
Copper, CPVC, PEX, Polyethylene
Fitting Body Material
Brass
For Tube OD
1/2 in x 1/2 in
End Connection Type
Push-to-Connect
For Tube Outside Diameter
1/2 in
Country of Origin (subject to change)
Australia
