Max. Water Level Adjustment
36
Float Switch On Point
45 Degrees Above Horizontal
Float Length (In.)
5-19/32
Pumping Range Min./Max.
8 to 36
Body Material
Polypropylene
Float Switch Float Material
Polypropylene
For Use With
Pumps with The Max Running Current Draw of 13 Amps or Less In The Liquid Temperatures of 200 Degrees or Less
Float Switch Cord Length
20 ft.
Max. Liquid Temp.
200 Degrees F
Min. Water Level Adjustment
8
Float Material
Polypropylene
Mounting Bracket Material
Stainless Steel
Electrical Connection (Pumps)
Piggyback
Float Switch Off Point
45 Degrees Below Horizontal
Turns Off At
45 Degrees Below Center
Float Switch Contact Form
Normally Open
Electrical Connection - Pumps
Piggyback
Minimum Tether Length
3 in
Switch Actuation
Tether Float
Electrical Connection
Piggyback
Maximum Tether Length
18 in
Off Point
45 Degrees Below Horizontal
Contact Default
Normally Open
On Point
45 Degrees Above Horizontal
Country of Origin (subject to change)
United States
