| Property | Value |
|---|---|
| CAD Available | Yes |
| Item | Self Locking Thread Insert |
| Internal Thread Size | 1/2 |
| Material | Carbon Steel |
| Overall Length | 5/8 in |
| Insert Diameter | 5/8 in |
| External Thread Size | 5/8 |
| Wall Type | Thin Wall |
| Thread Type | UNF Internal/UNC External |
| Drill Bit Size | 37/64 in |
| Installation Method | Screwdriver, Bolt/Nut, or Power Drive Tool |
| Minimum Installation Depth | 11/16 in |
| Tensile Strength (PSI) | 78,300 psi |
| Internal Thread Class | 2B |
| Brinell Hardness | 163 |
| Application | For Use on Metal |
| Power Driver | 4ZE58 |
| Tap Sizes | 5/8-11 |
| External Thread Class | 2A |
| Finish | Black Phosphate |
| Features | Pre-Applied Adhesive Activates On Installation, Vibration Resistant |
| Min. Full Thread Depth | 11/16 |
| Thread Direction | Right Hand |
| Series | E-Z LOK |
| Material Grade/Class | 12L14 |
| External Thread Fit | 2A |
| Full Cure Time | 72 hr |
| Internal Thread Fit | 2B |
| Tensile Strength | 78,300 psi |
| System of Measurement | Inch |
| Compatible Tap Size | 5/8 |
| Maximum Hole Diameter | 0.578 in |
| Compatible Material | Metal |
| Country of Origin (subject to change) | United States |
| Package Quantity | 5 |
Thin Wall Self Locking Thread Insert, 1/2"-20 Int Thrd Sz, Carbon Steel, 5 PK, E-Z Lok, Mfr#: 319-820-PK5
$9.79
Free shipping will be applied on orders over $50
Self Locking Thread Insert, Compatible Material Metal, Compatible Tap Size 5/8 In.-11, Drill Bit Size 37/64 in, External Thread Fit 2A, External Thread Size 5/8 In.-11, Finish Black Phosphate, Insert Diameter 5/8 in, Internal Thread Fit 2B, Internal Thread Size 1/2 In.-20, Material Steel, Material Grade/Class 12L14, Maximum Hole Diameter 0.578 in, Minimum Installation Depth 11/16 in, Overall Length 5/8 in, System of Measurement Inch, Thread Direction Right Hand
9999 in stock
