Switch Function
Maintained On/Maintained Off/Maintained On
Actuator Style
Standard Lever
Amps
15A @ 125VAC, 15A @ 250VAC
Stem Dia. and Thread Size
15/32-32UNS
Recommended Use
Aerial and Scissor Lifts, Agriculture and Material-Handling Equipment, Cranes and Construction, Factory-Floor Control Units, Machine Tool Equipment Manufacturers, Truck Mounted Tele-Handlers
Includes
Bushing, Case, Cover, Toggle Lever
Operating Temp. Range
-85 Degrees to 160 Degrees F
DC Contact Rating
20 A @ 28 V
Standards
CE, CSA, UL Listed
AC Contact Rating
15 A @ 125 V, 15 A @ 250 V
Product Type
Toggle Switch
Horsepower
1 hp @ 250V AC, 1/2 hp @ 125V AC
Resistance Properties
Dust Resistant, Shock Resistant, Watertight, Temperature Resistant, Vibration Resistant
Terminal Connection Type
Quick Connect Tab
Metal Actuator Finish
Silver
Operating Temperature - Minimum
-40 Degrees F
Operator Illumination Style
Non-Illuminated
Operating Temperature - Maximum
160 Degrees F
Mounting Hole Diameter
0.47 in
NEMA Enclosure Rating
13, 3, 3R, 4
Stem Thread Size
15/32-32 UNS-2A
Switch Function Configuration
On/Off/On
Country of Origin (subject to change)
United States
