Electrical Connections
DIN w/1/2
Application
Air Compressors, Car Wash Equipment, Industrial Water Control, Laundry Equipment, Pumps
Operating Pressure Differential Hot Water - Maximum
Not Rated
Operation Type
Pilot Operated
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
Coefficient of Volume (Cv)
43
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
Fluid Temperature - Maximum
180 Degrees F
Outlet Connection Type
NPT
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
NEMA Enclosure Rating
1, 2, 3, 3S, 4, 4X
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Operating Pressure Differential Light Oil - Minimum
5 psi
Ambient Temperature - Minimum
14 Degrees F
Environmental Rating
Corrosive, Hazardous, Indoor, Outdoor
Mounting Orientation
Vertical
Operating Pressure Differential Steam - Minimum
Not Applicable
For Media
Aggressive Gases, Aggressive Liquids, Air, Ammonia, Cryogenic Fluids, Fuel Oil, Hot Water, Inert Gases, Light Oil, Liquid Propane Gas, Natural Gas, Oxygen, Steam, Water
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Valve Positions
2-Position
Operating Pressure Differential Water - Maximum
125 psi
Operating Pressure Differential Air/Inert Gas - Minimum
5 psi
Operating Pressure Differential - Maximum
350 psi
Ambient Temperature - Maximum
140 Degrees F
Valve Starting Configuration
Normally Closed
Operating Pressure Differential Water - Minimum
5 psi
Operating Pressure Differential Air/Inert Gas - Maximum
350 psi
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
Operating Pressure Differential Light Oil - Maximum
90 psi
Operating Pressure Differential - Minimum
5 psi
Operating Pressure Differential Hot Water - Minimum
Not Applicable
Operating Pressure Differential Steam - Maximum
Not Rated
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Country of Origin (subject to change)
Mexico
