Electrical Connections
Wire Leads
Valve Design
2-Way/2-Position
Valve Configuration
Normally Closed
Body Material - Valves
Glass-Filled Nylon
Safe Working Water Pressure
135 psi
Body Material
Glass Filled Nylon
Coil Enclosure
Watertight and Dust Tight
Min. Operating Pressure Differential
0 psi
Valve Ways and Positions
2-Way/2-Position
Environmental Rating - Valves
Outdoor
Application
General Purpose
Coefficient of Volume
0.61
Seal Material - Valves
Buna-N
Max. Operating Pressure Differential Light Oil
80 psi
Max. Fluid Temp.
140 Degrees F
Max. Operating Pressure Differential Water
80 psi
Max. Operating Pressure Differential Air/Inert Gas
80 psi
Operation Type
Direct Acting
Outlet Connection Type
NPT
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Steam - Minimum
Not Applicable
Operating Pressure Differential Steam - Maximum
Not Rated
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Valve Positions
2-Position
Fluid Temperature - Maximum
140 Degrees F
Operating Pressure Differential Light Oil - Minimum
Not Applicable
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Operating Pressure Differential Hot Water - Maximum
Not Rated
Operating Pressure Differential - Minimum
0 psi
For Media
Air, Caustics, Inert Gases, Light Oil, Water
Ambient Temperature - Minimum
50 Degrees F
Ambient Temperature - Maximum
122 Degrees F
Operating Pressure Differential Hot Water - Minimum
Not Applicable
Coefficient of Volume (Cv)
0.61
Operating Pressure Differential Water - Minimum
Not Applicable
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
Operating Pressure Differential Water - Maximum
80 psi
Valve Starting Configuration
Normally Closed
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Minimum
Not Applicable
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
Operating Pressure Differential Light Oil - Maximum
80 psi
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Maximum
80 psi
Environmental Rating
Outdoor
Country of Origin (subject to change)
United States
