| Property | Value |
|---|---|
| Enclosure | Open |
| Protection | Break on the Control Circuit Drive, Line Supply Overvoltage Drive, Line Supply Phase Loss Drive, Line Supply Undervoltage Drive, Motor Phase Break Drive, Motor Phase Break Motor, Overcurrent Between Output Phases and Earth Drive, Overheating Drive, Overload of Output Voltage Drive, Overspeed Drive, Overvoltage's on the DC Bus Drive, Safe Torque Off Drive, Safe Torque Off Motor, Short-Circuit Protection Drive, Thermal Protection Drive, Thermal Protection Motor |
| Control Type | Local and Remote |
| Dynamic Braking | Yes |
| Input Frequency | 50 to 60 Hz |
| Item | Variable Frequency Drives |
| Output Frequency Range | 599 Hz |
| With Line Contactor / No Line Contactor | With Line Contactor |
| Output Voltage | 240V AC |
| Digital Readout | Output Current; Output Frequency; Output Voltage |
| Input Phase AC | Three |
| Adjustable Deceleration Time | 0.01 to 9,999 sec |
| Control Method | Local and Remote |
| Adjustable Acceleration Time | 0.01 to 9,999 sec |
| Standards | CE Certified, CSA Certified, IEC 13849-1, IEC 60721-3, IEC 61000-3-12, IEC 61508, IEC 61800-3, IEC 61800-5-1, REACH Regulation, RoHS Compliant, UL 508C, UL Listed, UV, WEEE |
| With Bypass / No Bypass | No Bypass |
| Input Voltage | 240V |
| Start/Stop Control | Programmable |
| Output Phase AC | Three |
| Brake Chopper Included | Yes |
| Output Type | Analog, Digital |
| Overall Width | 5 5/8 in |
| Overall Depth | 8 1/8 in |
| Number of Inputs | (10) Digital, (3) Analog |
| Application | Industrial |
| Series | ATV930 |
| Input Voltage Range | 200V AC to 240V AC |
| Input Type | Analog, Digital |
| Number of Outputs | (2) Analog, (2) Digital |
| Overall Height | 13 3/4 in |
| Output Voltage Range | 200V AC to 240V AC |
| Ethernet Port Included | Yes |
| Torque Application | Constant Torque, Variable Torque |
| Style | Compact |
| Color | Black/Green |
| Maximum Output Current | 4.6 A |
| Enclosure Rating | IP21 |
| Country of Origin (subject to change) | Indonesia |
| Package Quantity | 1 |
Variable Frequency Drives, 240V AC
$1836.99
Free shipping will be applied on orders over $50
Variable Frequency Drives, Input Voltage 240V, Input Phase AC Three, Input Frequency 50 to 60 Hz, Maximum Output Current 4.6 A, Output Voltage 240V AC, Output Phase AC Three, Output Frequency Range 599 Hz, Enclosure Rating IP21
9999 in stock
Subtotal:
$1836.99
