Safety Rating
CAT III 1000V, CAT IV 600V
AC Voltage Range
10.2 to 600
DC Voltage Range
10.2 to 600
Includes
Test Lead Wrap, TP2 Test Probes
Standards
CAN/CSA C22.2 No. 61010-1 Second Edition, IEC 61010-1 to 1000 V CAT III/600 V CAT IV Compliance to NFPA 70E1, ISA-82.02.01 (IEC 61010-1 Mod) (Second Edition)
Special Features
(3) Forms of AC/DC Voltage Indication: Light, Sound and Vibration for Added User Protection and Convenience, Detect Live Voltage Even When The Batteries are Dead, Extra Heavy Duty, Replaceable Test Leads for More Flexibility and Durability, Continuity Beeper, On/Off Switchable Beeper, Selectable According to Your Environment, Replaceable Test Probes for Added Flexibility and Convenience, Convenient Probe Storage On The Back, Probe Holder for Easier Testing, Hazardous Voltage Warning Light for Added User Protection, Auto Off Saves Battery Power
Basic DC Accuracy
+/-2% of Reading +2 Digits
Vibrates When Voltage Present
Yes
Manufacturers Warranty Length
2 yr
Display
Backlit LCD with Discrete LED
Features
Detect Live Voltage, See Voltage Level, Even with Dead Batteries
Calibration Frequency
45 to 66 Hz
Manufacturer Warranty Length
2 yr
DC Voltage Accuracy
+/-2.00% +2 digits
Battery Chemistry
Alkaline
Continuity Confirmation
9.99 kiloohm
Minimum Resistance Measured
0.01 kiloohm
Test Connection Type
Probe Tip
AC Voltage Accuracy
+/-3.00% + 2 digits
Minimum AC Voltage Measured
10.2 V
Product Type_Filter
Fluke-T+Pro
CAT Safety Rating
CAT III 1000V, CAT IV 600V
Number of Batteries Required
2
Tester Type
Voltage Detector/Tester
Maximum Operating Temperature
131 Degrees F
Maximum AC Voltage Measured
600 V
Minimum Current Measured
6 mA
Maximum Current Measured
9 mA
Alert Type
Audible, Visual
Maximum DC Voltage Measured
600 V
Minimum Operating Temperature
14 Degrees F
Maximum Resistance Measured
9.99 kiloohm
Minimum DC Voltage Measured
10.2 V
Maximum Operating Temperature
131 Degrees F
Country of Origin (subject to change)
China
