Electrical Connections
Wire Leads
Valve Design
2-Way/2-Position
Valve Configuration
Normally Closed
Body Material - Valves
PVC
Safe Working Water Pressure
125 psi
Environmental Rating - Valves
Indoor, Outdoor
Valve Ways and Positions
2-Way/2-Position
Max. Fluid Temp.
140 Degrees F
Application
For Use in Severe Service Applications with Most Liquids, Including Acids, Caustics, Chlorine Solutions, Solvents and Ultrapure Fluids.
Coefficient of Volume
2.00
Min. Operating Pressure Differential
0 psi
Coil Enclosure
Watertight No Junction Box
Operation Type
Direct Acting
Actuator Type
Spring Return
Operating Pressure Differential Water - Maximum
Not Rated
Operating Pressure Differential Water - Minimum
Not Applicable
Ambient Temperature - Maximum
122 Degrees F
Operating Pressure Differential Natural Gas - Maximum
Not Applicable
Coefficient of Volume (Cv)
2
Operating Pressure Differential Fuel Oil - Maximum
Not Applicable
Operating Pressure Differential Liquid CO2 - Maximum
Not Applicable
Operating Pressure Differential Fuel Oil - Minimum
Not Applicable
Environmental Rating
Indoor, Outdoor
Fluid Temperature - Maximum
140 Degrees F
Mounting Orientation
Horizontal or Vertical
Operating Pressure Differential Hot Water - Maximum
Not Rated
Operating Pressure Differential Fuel Gas - Minimum
Not Applicable
Valve Starting Configuration
Normally Closed
Operating Pressure Differential Fuel Gas - Maximum
Not Applicable
Valve Positions
2-Position
Outlet Connection Type
NPT
For Media
Acids, Caustics, Chlorine Solution, Solvents, Ultra-Pure Liquids
Operating Pressure Differential - Minimum
0 psi
Operating Pressure Differential Light Oil - Minimum
Not Applicable
Operating Pressure Differential Cryogenic Fluid - Minimum
Not Applicable
Operating Pressure Differential Steam - Minimum
Not Applicable
Operating Pressure Differential Hot Water - Minimum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Maximum
Not Rated
Operating Pressure Differential Cryogenic Fluid - Maximum
Not Applicable
Operating Pressure Differential Air/Inert Gas - Minimum
Not Applicable
Operating Pressure Differential Natural Gas - Minimum
Not Applicable
Operating Pressure Differential Liquid CO2 - Minimum
Not Applicable
Operating Pressure Differential Steam - Maximum
Not Rated
Operating Pressure Differential Light Oil - Maximum
Not Rated
Country of Origin (subject to change)
United States
