Application
Electronics, Medical Equipment Manufacturing
Barcode Scanner Type
Corded Barcode Label Scanner
Model Number
DS3608-SR3U4600VZW
Includes
Drivers, Test Utilities, Sample Source Code
Min. Operating Temp.
-22 Degrees F
Max. Operating Temp.
122 Degrees F
Operating Temp. Range
-22 Degrees F to 122 Degrees F
Connection Type
USB, RS232, Keyboard Wedge, Industrial Ethernet: EtherNet/IP, Profinet, Modbus, TCP and Std TCP/IP
Data Capture
1D: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma), 2D: PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes, DotCode
Printer Connectivity
RS232, USB
Image Scan Type
1D Scanner, 2D Scanner
Power Source
Host Power, External Power Supply, Lithium Ion Battery
Product Type
Barcode Scanner Kit
Country of Origin (subject to change)
Mexico
