Output Test Voltage
500/1000/2500/5000V DC
Insulation Resistance Range
0 ohm to 60 gigohm
Accuracy
+/-2.5% of Reading
Resistance Range
60 gigohm
Display
Backlit LCD with Bar Graph
Features
1 to 15 Minute Timer Function for IR Measurements, Auto-Discharge Function and Voltage Output Warning Function, Dielectric Absorption Ratio Measurement, Indication of Output Voltage and Discharge Voltage, Polarization Index Measurement (PI), Resistance Measurement
Includes
120V AC Adapter, Heavy Duty Carrying Case, Test Leads
Calibration Certificate
Not Included
Maximum AC Voltage Measured
600 V
Greater Than 30V Warning
Yes
Testing Functions
Insulation
Maximum DC Voltage Measured
600 V
Test Voltage
1,000V DC, 2,500V DC, 5,000V DC, 500V DC
Timed Ramp Voltage Test
No
Standards
IEC 61010-031, IEC 61010-1
CAT Safety Rating
CAT IV 600V
Minimum Operating Temperature
0 Degrees F
Operating Voltage
0.5 to 600V AC
Manufacturer Warranty Length
2 yr
USB Data Download Included
No
Maximum Insulation Resistance
60 gigohm
Pass/Fail Selection Limits
No
Maximum Operating Temperature
104 Degrees F
Remote Test Probe Included
No
Megohmmeter Features
Standard
Number of Batteries Required
8
Minimum AC Voltage Measured
0.5 V
Capacitance Auto Discharge
Yes
Backlit Digital Display
Yes
Insulation Resistance Resolution
0 to 600M Ohms, 0 to 60G Ohms, 0 to 60M Ohms, 0 to 6G Ohms, 0 to 6M Ohms
Minimum Insulation Resistance
0 ohm
Minimum DC Voltage Measured
0.5 V
Parameters Measured
Resistance
Resistance Accuracy
+/-2.50%
Maximum Operating Temperature
104 Degrees F
Country of Origin (subject to change)
China
