| Property | Value |
|---|---|
| Body Material | Polycarbonate |
| Tubing Material - Peristaltic Pumps | Santoprene |
| Min. Flow Rate | 2.70 gpd |
| Includes | 20 ft Roll of Suction/Discharge Tubing, Pump Tube, Duckbill Check Valve, Weighted Suction Line Strainer, (3) 1/4 in Connecting Nuts, (3) 1/4 in Ferrules |
| HP - Pumps | 1/40 hp |
| Seals and O-Rings - Pumps | Santoprene |
| Max. Flow (GPD) - Pumps | 23.50 gpd |
| Height | 5 1/2 in |
| Length | 6 in |
| Turn Down Ratio - Pumps | 8:1 |
| Voltage - Pumps | 115V AC |
| Phase - Pumps | 1 |
| Flow Rate Output Control | Variable |
| Width | 3 3/4 in |
| Max. Flow (gpd) - Pumps | 23.50 gpd |
| Cord Length | 6 ft |
| Max. Pressure - Pumps | 80 psi |
| Item | Chemical Metering Pump |
| Item - Chemical Metering Pumps | Chemical Metering Pump |
| Pump RPM | 44 RPM |
| Self-Priming | Yes |
| cc/Min. | 61.67cc/mΓn. |
| Standards | CE Certified, cULus Listed |
| Suction Lift | 25 ft |
| Max. Viscosity - Pumps | 100 cps |
| Features | Compact, Patented Quick Release Pump Head, Variable Output Adjustment |
| Motor RPM | 3,250 RPM |
| Chemical Metering Pump Type | Peristaltic |
| Flow Rate | 0.016 gpm/0.061Lpm |
| Reproducibility - Pumps | +/-5.0% |
| Head and Fitting Material - Pumps | Polycarbonate/Polypropylene/PVC |
| Number of Feeds | Single Head |
| Hz | 60 |
| Overall Length | 4.4 in |
| Pressure (Maximum) | 80 psi |
| Metering Reproducibility | +/-5.0% |
| Head Material | Polyethylene |
| Viscosity (Maximum) | 100 cps |
| Max. Flow Rate | 23.5 gpd |
| Discharge Connection Size | 1/4 in |
| Flow Rate (Maximum) | 23.5 gpd |
| Duty Cycle | Continuous |
| Frequency | 60 Hz |
| Reproducibility | +/-5.0% |
| Electrical Connection Type | Plug-In |
| Motor Mounting Type | Not Applicable |
| Seal Material | Santoprene |
| Nameplate Voltage | 120V AC |
| Phase | Single |
| Motor Type | Brushed DC |
| Media Temperature (Maximum) | 104 Degrees F |
| Tubing Material | Santoprene |
| Ambient Temperature (Maximum) | 104 Degrees F |
| Fitting Material | Polypropylene, PVC |
| Degassing Valve Included | No |
| Intake Connection Type | Tube |
| Horsepower (Maximum) | 1/40 hp |
| Turn Down Ratio | 8:1 |
| Priming | Self-Priming |
| Overall Height | 5.9 in |
| Max. Discharge Pressure | 25 psi |
| Motor Enclosure | Totally Enclosed |
| Chemical Compatibility | Ammonium Hydroxide, Antifreeze, Hydrochloric Acid 10%, Hydrochloric Acid 20%, Hydrochloric Acid 30%, Phosphoric Acid 100%, Phosphoric Acid 40%, Phosphoric Acid 50%, Phosphoric Acid 60%, Phosphoric Acid 70%, Phosphoric Acid 80%, Phosphoric Acid 90%, Potassium Hydroxide 50%, Sodium Hydroxide 20%, Sodium Hypochlorite 10%, Sodium Hypochlorite 5%, Sulfuric Acid 10%, Sulfuric Acid 20%, Sulfuric Acid 30%, Sulfuric Acid 40%, Water |
| Roller Material | Polyethylene |
| Housing Material | Polycarbonate |
| Intake Connection Size | 1/4 in |
| Media Temp. Range | 32 Degrees F to 104 Degrees F |
| Media Temperature (Minimum) | 32 Degrees F |
| Motor Speed (Maximum) | 3,250 RPM |
| Discharge Connection Type | Tube |
| Flow Rate (Minimum) | 2.94 gpd |
| Overall Width | 5.2 in |
| Control Programs | Manual Control |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Pump, Peristaltic, Max. Flow 23.50 gpd, Stenner, Mfr#: E20VXHA1S6G1
$389.99
Free shipping will be applied on orders over $50
Chemical Metering Pump
9999 in stock
Subtotal:
$389.99
