| Property | Value |
|---|---|
| Item | Clutch/Brake |
| For Use With | NEMA C-Face Motor/Reducer |
| Length (In.) | 8.875 in |
| Shaft Dia. (In.) | 1 1/8 in |
| Width (In.) | 10 in |
| Static Torque (Ft.-Lb.) | 95 |
| NEMA/IEC Frame | 213C/182TC/215C/184TC |
| Enclosure | Totally Enclosed Nonventilated |
| Max. RPM | 3,600 RPM |
| Mounts On | NEMA C-Face Motor or Between Motor and Reducer |
| Finish | Black Paint |
| Power Lead Length (In.) | 30 |
| Voltage (DC) | 90 |
| Agency Compliance | UL/CSA |
| Brake Mouting Position | Horizontal |
| Includes | Mounting Hardware |
| Series | EUM-210 |
| Overall Width | 10 in |
| Overall Length | 8.88 in |
| Enclosure Type | Totally Enclosed Nonventilated |
| Operating Voltage | 90V DC |
| Mounting Orientation | Horizontal |
| Coil Voltage | 90V DC |
| Shaft Diameter | 1 1/8 in |
| Maximum Speed | 3,600 RPM |
| Static Torque | 95 ft-lb |
| Lead Length | 30 in |
| Motor Frame Designation | 213C NEMA |
| Housing Material Finish | Black Paint |
| Standards | CSA Certified, UL Listed |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Clutch/Brake, Torque 95 Ft-Lb, 90 DC, Warner Electric, Mfr#: EUM210-1020
$4526.99
Free shipping will be applied on orders over $50
Clutch/Brake, Coil Voltage 90V DC, Operating Voltage 90V DC, Enclosure Type Totally Enclosed Nonventilated, Static Torque 95 ft-lb, Motor Frame Designation 213C NEMA, Shaft Diameter 1 1/8 in, Maximum Speed 3,600 RPM, Mounting Location NEMA C-Face Motor or Between Motor and Reducer, For Use With NEMA C-Face Motor/Reducer, Includes Mounting Hardware, Lead Length 30 in, Overall Length 8.88 in, Overall Width 10 in, Phase -, Service Factor -, Standards CSA Certified, UL Listed, Application -
9999 in stock
