| Property | Value |
|---|---|
| Item | Combustion Analyzer |
| Type | Residential/Commercial |
| Fuel Type | Natural Gas, Propane |
| Combustion Efficiency | 0 to 99.9% |
| Oxygen Concentration | 0 to 21% |
| Carbon Dioxide Concentration | 0 to 20% |
| Stack Temp. | -40 Degrees to 950 Degrees F |
| Excess Air | 0 to 250% |
| Manufacturers Warranty Length | 1 yr Limited |
| Calibration Certificate Included | Yes |
| Features | 3 Types of Sensor Protection, Automatic Fresh Air Purge, Digital, Link to Wireless Probes, Low Flow Detection, Memory Positions 30, NOx Filtered, Over Range Protection Pump, Preprogrammed Fuels 8, Protective Boot or Overmolding, Temperature Inputs K-Type |
| Display | 6 Line Backlight |
| Carbon Monoxide Measurement Range | 0 to 10,000 ppm |
| Battery Type | AA Rechargeable |
| Pressure/Draft | +/-0.4 in WC to +/-32 in WC |
| Nitric Oxide Measurement Range | 0 to 100 ppm |
| Includes | (2) ATT29 K Type Thermocouples, (2) Wireless Pipe Clamp Probes, Printer Paper Roll, Particle Filter, USB Cable, Soft Carrying Case, Flue Probe, IRP-2 Infrared Printer |
| Primary/Ambient Air Temp. | 32 Degrees to 112 Degrees F |
| Analyzer Type | Residential/Commercial |
| Display Type | Backlit Digital |
| Minimum Carbon Dioxide Measured | 0 % v/v |
| Calibration Certificate Type | NIST |
| Maximum Carbon Monoxide Measured | 10,000 ppm |
| Battery Size | AA |
| Selectable Fuel Options | Butane, Heavy Oil, Light Oil, LPG, Natural Gas, Pellets, Propane |
| Minimum Excess Air Measured | 0 % |
| Minimum Combustion Efficiency | 0 % |
| Maximum Stack Temperature Measured | 1,112 Degrees F |
| Number of Batteries Required | 3 |
| Batteries Included | Yes |
| Minimum Carbon Monoxide Measured | 0 ppm |
| Maximum Carbon Dioxide Measured | 20 % v/v |
| Manufacturer Warranty Length | 10 yr |
| Maximum Operating Temperature | 113 Degrees F |
| Digital Display Screen Type | LCD with Backlight |
| Minimum Oxygen Measured | 0 % v/v |
| Minimum Stack Temperature Measured | 32 Degrees F |
| Maximum Excess Air Measured | 250 % |
| Maximum Combustion Efficiency | 99.9 % |
| Maximum Oxygen Measured | 21 % v/v |
| Battery Chemistry | Alkaline |
| Minimum Operating Temperature | 32 Degrees F |
| Country of Origin (subject to change) | United Kingdom |
| Package Quantity | 1 |
Combustion Analyzer, 32to113F, 21% v/vO2, Uei Test Instruments, Mfr#: C165+KIT-N
$1997.99
Free shipping will be applied on orders over $50
Combustion Analyzer, Digital Display Screen Type LCD with Backlight, Maximum Carbon Monoxide Measured 10,000 ppm, Maximum Oxygen Measured 21 Percent v/v, Minimum Oxygen Measured 0 Percent v/v, Selectable Fuel Options Butane, Heavy Oil, Light Oil, LPG, Natural Gas, Pellets, Propane, Minimum Carbon Monoxide Measured 0 ppm, Maximum Combustion Efficiency 99.9 Percent, Minimum Combustion Efficiency 0 Percent, Maximum Excess Air Measured 250 Percent, Minimum Excess Air Measured 0 Percent
9999 in stock
