| Bore Dia. | 30 mm |
| Outside Dia. | 72 mm |
| Width | 19 mm |
| Roller Material | Alloy Steel |
| Cage Material | Brass |
| Static Load Capacity (Lb.) | 11,240 lb |
| Fillet Radii (mm) | 1.1 mm / 1.1 mm |
| Outside Dia. Tolerance | +0/-0.013mm |
| Tolerance | +0/-0.010mm |
| Dynamic Load Capacity (Lb.) | 11,914 lb |
| Temp. Range (F) | -13 Degrees to 250 Degrees F |
| Shoulder Height (mm) | 44.9 mm |
| Item | Cylindrical Roller Bearing |
| Inner Ring Outside Dia. (mm) | 40.5 mm |
| Shaft Fillet Radius | 1.1 mm |
| Lubrication Openings | None |
| Number of Rows | One |
| Minimum Temperature | -40 Degrees C |
| System of Measurement | Metric |
| Retaining Ring Material | Not Applicable |
| Bore Type | Cylindrical |
| ISO Rating | Class 0 |
| Closure | Open |
| Maximum Speed | 11,000 RPM Oil, 9,300 RPM Grease |
| Roller Material Grade | 52100 |
| RBEC Rating | 1 |
| Outer Ring Inside Diameter | 65.5 mm |
| Full Complement | No |
| Maximum Temperature | 120 Degrees C |
| Retaining Ring Thickness | Not Applicable |
| Brand & Part Number for Bearing Industry Number | NTN NJ306EG1C3 |
| Ring Material | Alloy Steel |
| Bearing Industry Number | 306 |
| Static Radial Load Capacity | 50,000 N |
| Overall Width | 19 mm |
| Number of Inner Ring Flanges | 1 |
| Seal Type | Not Applicable |
| Dynamic Radial Load Capacity | 53,000 N |
| Outside Diameter Tolerance | +0/-0.013 mm |
| Retaining Ring Diameter | Not Applicable |
| Cylindrical Bearing Design | NJ |
| Split Bearing | Yes |
| Number of Outer Ring Flanges | 2 |
| Bore Diameter Tolerance | +0/-0.010 mm |
| Housing Fillet Radius | 1 mm |
| Outside Diameter | 72 mm |
| Inner Ring Outside Diameter | 36.5 mm |
| Retaining Ring Groove | Not Applicable |
| Lubricant Material | Grease, Oil |
| Ring Material Grade | 52100 |
| Bore Diameter | 30 mm |
| Seal Material | Not Applicable |
| Includes Retaining Ring | No |
| Country of Origin (subject to change) | Japan |
| Package Quantity | 1 |
Cylindrical Bearing, 30mm Bore, 72mm OD, NTN, Mfr# NJ306EG1C3
$90,19
Free shipping will be applied on orders over $50
Cylindrical Roller Bearing, Bearing Industry Number 306, Bore Diameter 30 mm, Bore Type Cylindrical, Cage Material Brass, Closure Open, Inner Ring Outside Diameter 36.5 mm, Lubricant Material Grease, Oil, Maximum Speed 11,000 RPM Oil, 9,300 RPM Grease, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outer Ring Inside Diameter 65.5 mm, Outside Diameter 72 mm, Overall Width 19 mm, Ring Material Alloy Steel, Roller Material Alloy Steel
