Item | DC Power Solenoid |
Coil Voltage DC | 12 V DC |
Amps | 100 |
Contact Form | SPST-NO |
Duty Cycle | Continuous |
Coil Termination | #10-32 |
Contact Material | Silver Alloy |
Series | 120 |
Enclosure | Dust And Water Resistant |
Mounting Base | Standard Bracket |
Coil Type | Isolated |
Contact Termination | 5/16 in-24 |
Coil Resistance | 16 ohm |
Height | 3.09 in |
Temperature Range | -20 to 120°F |
Width | 2.88 in |
Length | 2.13 in |
Contact Rating | 12A |
Dielectric Strength | 500 V |
Coil Voltage | 12 V DC |
Maximum Operating Temperature | 120 Degrees F |
Current Rating | 12 A |
Power Consumption | 8.1 W |
Mechanical Operating Durability | 100,000 |
Weight | 6 oz |
Resistance Properties | Dust Resistant, Water Resistant |
Minimum Operating Temperature | -20 Degrees F |
Electrical Operating Durability | 50,000 |
Country of Origin (subject to change) | Mexico |
Package Quantity | 1 |
DC Power Solenoid, 12V, Amps 100, WHITE-RODGERS, Mfr# 120-105711
$22,99
Free shipping will be applied on orders over $50
DC Power Solenoid, Current Rating 12 A, Contact Form SPST-NO, Coil Voltage 12 V DC, Duty Cycle Continuous, Contact Termination 5/16 in-24, Series 120, Coil Resistance 16 ohm, Coil Termination #10-32, Coil Type Isolated, Contact Material Silver Alloy, Dielectric Strength 500 V, Electrical Operating Durability 50,000, Height 3.09 in, Includes -, Length 2.13 in, Maximum Operating Temperature 120 Degrees F, Mechanical Operating Durability 100,000, Minimum Operating Temperature -20 Degrees F
9999 in stock
Must order in multiples of 1
Subtotal:
$22.99
