| Property | Value |
|---|---|
| Item | DC Power Solenoid |
| Coil Voltage DC | 24 V DC |
| Amps | 100 |
| Contact Form | SPST-NO |
| Duty Cycle | Continuous |
| Coil Termination | #10-32 UNF-2A Thread |
| Series | 124 |
| Coil Type | Isolated |
| Contact Termination | 5/16 in-24 UNF-2A Thread |
| Includes | Not Applicable |
| Contact Material | Silver Alloy |
| Mounting Base | Standard Bracket |
| Enclosure | Dust Resistant |
| Length | 3.56 in |
| Width | 3.13 in |
| Contact Rating | 24A |
| Coil Resistance | 53 ohm |
| Temperature Range | -40 to 149ΓΒ°F |
| Height | 2.19 in |
| Minimum Operating Temperature | -40 Degrees F |
| Weight | 16 oz |
| Resistance Properties | Dust Resistant, Water Resistant |
| Maximum Operating Temperature | 149 Degrees F |
| Current Rating | 150 A |
| Coil Voltage | 24 V DC |
| Number of Terminals | 4 |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
DC Power Solenoid, 24V, Amps 100, White-Rodgers, Mfr#: 124 114111S1
$53.19
Free shipping will be applied on orders over $50
DC Power Solenoid, Current Rating 150 A, Contact Form SPST-NO, Coil Voltage 24 V DC, Duty Cycle Continuous, Contact Termination 5/16 in-24 UNF-2A Thread, Series 124, Coil Resistance 53 ohm, Coil Termination #10-32 UNF-2A Thread, Coil Type Isolated, Contact Material Silver Alloy, Height 2.19 in, Includes Not Applicable, Length 3.56 in, Maximum Operating Temperature 149 Degrees F, Minimum Operating Temperature -40 Degrees F, Mounting Base Standard Bracket, Number of Terminals 4
9999 in stock
Subtotal:
$53.19
