Item | DC Power Solenoid |
Coil Voltage DC | 36 V DC |
Amps | 200/100 |
Contact Form | SPST-NO |
Duty Cycle | Continuous |
Coil Termination | #10-32 UNF-2A Thread |
Series | 586 |
Contact Material | Silver Alloy |
Enclosure | Water Resistant |
Coil Type | Isolated |
Mounting Base | Standard Bracket |
Contact Termination | 5/16 in-24 UNF-2A thread |
Contact Rating | 36A |
Temperature Range | -40 to 149°F |
Length | 3.69 in |
Coil Resistance | 189 ohm |
Height | 2.9 in |
Width | 3.3 in |
Coil Voltage | 36 V DC |
Mechanical Operating Durability | 100,000 |
Weight | 24 oz |
Maximum Operating Temperature | 149 Degrees F |
Power Consumption | 8 W |
Electrical Operating Durability | 50,000 |
Resistance Properties | Dust Resistant, Water Resistant |
Current Rating | 36 A |
Minimum Operating Temperature | -40 Degrees F |
Dielectric Strength | 500 V |
Country of Origin (subject to change) | Mexico |
Package Quantity | 1 |
DC Power Solenoid, 36V, Amps 200, WHITE-RODGERS, Mfr# 586-117111
$68,89
Free shipping will be applied on orders over $50
DC Power Solenoid, Current Rating 36 A, Contact Form SPST-NO, Coil Voltage 36 V DC, Duty Cycle Continuous, Contact Termination 5/16 in-24 UNF-2A thread, Series 586, Coil Resistance 189 ohm, Coil Termination #10-32 UNF-2A Thread, Coil Type Isolated, Contact Material Silver Alloy, Dielectric Strength 500 V, Electrical Operating Durability 50,000, Height 2.9 in, Includes -, Length 3.69 in, Maximum Operating Temperature 149 Degrees F, Mechanical Operating Durability 100,000
9999 in stock
Must order in multiples of 1
