| Property | Value |
|---|---|
| Type | Belleville |
| For Rod Size | 0.5 |
| Material | 302 Stainless Steel |
| For Hole Size | 1.375 |
| Thickness | 0.1 in |
| Overall Height | 0.12 in |
| Min. Inside Dia. | 0.531 in |
| Max. Outside Dia. | 1.375 in |
| Load @ Deflection (Lbs.) | 1274 to 1724 |
| Deflection @ Load | 0.016 in |
| Item | Disc Spring |
| Meets/Exceeds | ASI 302 and Government AMS Type 302 |
| Calculated Load @ Flat (Lbs.) | 1846 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 6 |
Disc Spring, Belleville, 0.5,302 SS, PK6, EnjoyTool Select, Mfr#: 1NEK7
$14.19
Free shipping will be applied on orders over $50
Disc Spring, Belleville, 302 Stainless Steel, Min Inside Dia 0.531 In, Max Outside Dia 1.375 In, Thickness 0.100 In, Overall Height 0.120 In, Load 1280 Lbs, Deflection @ Load 0.016 In, Flat Load 38 Lbs, Meets/Exceeds ASI 302 and Government AMS Type 302, Package 6
9999 in stock
