Housing Material - Pumps
Aluminum
Diaphragm Material - Pumps
Santoprene(R)
Item - Air Operated Pumps
Double Diaphragm Pump
Max. Temp - Pumps
300 Degrees F
Air Inlet Size
1/2 in FNPT
Agency Compliance
ABS, ATEX, CE, EAC
Ball Material
Santoprene(R)
Operation Type
Air Operated
Manifold Connection
Single Port
Manufacturers Warranty Length
1 yr
Check Seat Material
Santoprene
Item
Double Diaphragm Pump
Diaphragm Material
Santoprene
Max. Operating Pressure
125 psi
Flow Rate @ 80 psi
234 gpm
Feet of Head (Maximum)
320 ft
Port Location
Bottom Top, Center Center, Center Top
Air Intake Pressure (Maximum)
125 psi
Flow Rate @ 60 psi
226.7 gpm
Air Consumption (Maximum)
180 scfm
Flow Rate @ 120 psi
Not Applicable
Flow Rate @ 15 psi
Not Applicable
Solid Diameter (Maximum)
0.38 in
Chemical Compatibility
Alcohol, Ammonium Hydroxide, Water
Overall Size
15 in x 25.1 in x 32.1 in
Fluid Discharge Connection
3 in NPT
Media Intake Connection Size
3 in
Flow Rate @ 70 psi
Not Applicable
Manifold Connection Type
NPT
Flow Rate (Maximum)
273 gpm
Air Intake Connection Type
NPT
Flow Rate @ 30 psi
Not Applicable
Flow Rate @ 50 psi
Not Applicable
Wetted Housing Material
Aluminum
Flow Rate @ 40 psi
214.1 gpm
Fluid Connection Size
3 in
Media Intake Connection Type
NPT
For Use With Potable Systems
No
Flow Rate @ 90 psi
Not Applicable
Flow Rate @ 100 psi
241 gpm
Air Intake Connection Size
1/2 in
Media Discharge Connection Size
3 in
Flow Rate @ 10 psi
Not Applicable
Media Temperature (Maximum)
300 Degrees F
Media Intake Location
Bottom, Center
Operating Pressure (Maximum)
125 psi
Flow Rate @ 20 psi
170.9 gpm
Media Discharge Location
Center, Top
Fluid Intake Connection
3 in NPT
Non-Wetted Housing Material
Aluminum
Media Discharge Connection Type
NPT
Country of Origin (subject to change)
United States
