| Property | Value |
|---|---|
| Type | Double, Friction Bearing |
| Outside Dia. | 0.995 in (25.3 mm) |
| Bore | 0.5000 in x 11 mm |
| Lubrication | LUBRIPLATE No. 1200-2 |
| SAE or Metric | Inch/Metric |
| Keyway | 1/8 in x 4 mm |
| Material | 303 Stainless Steel |
| Weight | 0.765 lbs |
| Length | 4.875 in (123.8 mm) |
| B1 Shaft Penetration | 1.190 in (30.2 mm) |
| Bore Tolerance | +0.0010 in / -0.0000 in (+0.025 mm / -0.000 mm) |
| Max Operating Angle | 90° |
| Matching Boot | UBOOT16/25-NI-KIT |
| Yoke Length (LY) | 1.688 in (42.9 mm) |
| B2 Shaft Penetration | 1.190 in (30.2 mm) |
| Style | Roud Bore, Set Screw, Keyway |
| Rated Torque | 284 in-lb (32.1 Nm) |
| Max. Torque | 1420 in-lb (160.4 Nm) |
| Hub Depth | 1.190 in (30.2 mm) |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Double U-Joint, 1/2" x 11 mm Bores, 0.995" (25.3 mm) OD, Stainless, Ruland, Mfr#: UDSK16-1/2"-11MM-SS
$817.99
Free shipping will be applied on orders over $50
This Ruland double friction bearing universal joint with set screws has 0.5000" x 11mm bores, a 0.995" (25.3mm) outer diameter, and a 4.875" (123.8mm) length. It is ideal for applications with wide distances between shafts and can accommodate all forms of misalignment. This double universal joint is made of two blocks, four pins, one center spacer, and two yokes. These components are manufactured to tight tolerances using proprietary processes that ensure smooth operation and high misalignment accommodation up to 90°, which is a significant improvement over commodity style double universal joints. It is made from stainless steel for corrosion resistance. The user can add boots to protect the joints from unwanted contaminants and increase service life. This double friction bearing universal joint is manufactured in the USA.
9999 in stock
