| Property | Value |
|---|---|
| Item | Female Disconnect |
| Insulation | None |
| Insulation Color | Bare |
| Connection Type | Crimp |
| Insulation Type | Bare |
| Wire Range | 16 to 14 AWG |
| Overall Length | 0.66 in |
| Tab Size | 0.032 in x 0.250 in |
| Seam | Butted |
| Max. Temp. | 347 Degrees F |
| Max. Voltage | 600 V |
| Standards | CSA Certified, RoHS Compliant, UL Listed |
| Barrel Inside Dia. | 0.08 in |
| Connection Material | Brass |
| Terminal Type | Female Disconnect |
| Barrel Inside Diameter | 0.080 in |
| Minimum Conductor Size | 16 AWG |
| Pad Width | 0.25 in |
| Disconnect Type | Female |
| Mates with Female Width | 0.250 in |
| Tab Width | 0.25 in |
| Fastener Orientation | Female |
| Solution for | Wireless Network Infrastructure Accessories |
| Insulation Material | Non-insulated |
| Maximum Conductor Size | 14 AWG |
| Terminal Style | Standard |
| Mates with Male Tab Width (W') | 0.250 in |
| Connection Width | 0.25 in |
| Country of Origin (subject to change) | United States |
| Package Quantity | 100 |
Scotchlok Female Disconnect, Bare, 16-14AWG, PK100, 3M, Mfr#: MU14-250DFX
$69.89
Free shipping will be applied on orders over $50
Female Disconnect, Insulation Color Bare, Terminal Type Female Disconnect, Standards CSA Certified, RoHS Compliant, UL Listed, Insulation Type Bare, Overall Length 0.66 in, Package Quantity 100
9999 in stock
