Housing Material
Cast Aluminum
Duty Cycle
30 Minutes On/30 Minutes Off
For Use With
Diesel, Gasoline, Kerosene, E15
Includes
Automatic Unleaded Nozzle, Dispensing Hose with Static Wire, Lockable Nozzle Holder, Pump with Spin Collar, Tank Adapter, Telescoping Suction Pipe
Compatible Fluids
Diesel, Gasoline, Kerosene, E15
Max. Head - Pumps
4 4/5 ft
Motor Enclosure
Explosion Proof
Wetted Materials
Not Applicable
Features
Self priming, Powder-coated aluminum body,telescoping suction pipe (15in - 40in), Easy installation spin collar mount, Explosion Proof Motor, Thermal Overload Protection
Housing Material - Pumps
Aluminum
Manufacturers Warranty Length
2 yr
Transfer Pump Application
Stationary Locations in Fleet
Standards
Class I Div 2, cULus Listed, IECEx/ATEX Zone 1
Cord Length
Not Applicable
Agency Compliance
Class I Div 2, cULus
Hose Tube Material
Nitrile
Housing Finish
Powder Coated
Hose Cover Material
Nitrile
For Media Type
Diesel, Gasoline, Kerosene
Adapter Connection Type
MNPT
Max. Outlet Pressure
15 psi
Compatible Chemicals
Diesel, Gasoline, Kerosene
Max. Fluid Temp.
125 Degrees F
Diesel Exhaust Fluid Compatible
No
Meter Unit Of Measure
Not Applicable
Suction Tube Material
Polypropylene
Nozzle Fluid Compatibility
Diesel
Nozzle Operation
Automatic
Height Above Container
11 in
For Container Size
10 gal, 500 gal
Includes Discharge Hose
Yes
Min. Fluid Temp.
-20 Degrees F
Filter Included
Not Applicable
Discharge Connection Type
FNPT
Country of Origin (subject to change)
United States
