Includes
Dual Cover Interlock
Neutral Assembly Included
Yes
Standards
EU RoHS, UL listed file E2875
For Fuse Class
Class H, Class K
Number of Mounting Holes
8
Maximum Enclosure Depth
7.16 in
Mounting Style
Surface Mount
Features
Quick Make/Break Operating Mechanism, Viewing Window
Includes Interlocked Receptacle
Yes
Housing Material
Galvannealed Steel
Horsepower @ 600V AC
50 hp
Fuse Kit (Class R)
Mfr. No. RFK03H
Horsepower @ 480V AC
30 hp
Compatible with Manufacturer Model Number
RFK03H
Horsepower @ 240V AC
Not Rated
Compatible with Manufacturer Model Number [NEW]
RFK03H
Compatible Manufacturer Part Number
RFK03H
Compatible Manufacturer Model Number
RFK03H
For Use with Mfr. Model Number
RFK03H
For Use With Mfr. Model Number
RFK03H
Device Composition
neutral (factory installed)
Wiring Configuration
4-wire (3PH + N)
Fuse Type
H or K || R or J
Short-Circuit Current
10 kA for H, K, J or R without fuse rejection clips || 200 kA for R with fuse rejection clips || 200 kA for J
Nema Degree Of Protection
NEMA 12 galvannealed steel
Disconnector Device Type
fusible disconnect
Condition Of Use
suitable service entrancefor USA || suitable service entrancefor Mexico
Device Application
heavy application
Awg Gauge
AWG 14...AWG 3 copper || AWG 12...AWG 3 aluminium
Product Certifications
UL listed file E2875
Tightening Torque
50-50 lbf.in (AWG 3) || 45-45 lbf.in (AWG 6...AWG 4) || 40-40 lbf.in 8.367-8.367 mm² (AWG 8) || 50-50 lbf.in 2.06-5.261 mm² (AWG 14...AWG 10)
[Ue] Rated Operational Voltage
600 V AC/DC
Electrical Connection
lugs
Product Or Component Type
Single Throw Safety Switch
Country of Origin (subject to change)
United States
