Wiring Method
Back and Side
Application Environment
Commercial
Material
Polycarbonate/Thermoplastic
Temperature Rise
Max 30C after 100 cycles OL at 150 percent rated current
Operating Temperature
-35C to +66C
Short Circuit Current Rating
10KA
Terminal Screws
Plated Steel
Termination
Back u0026 Side
Grounding Screw
Plated Steel
CSA-C22.2 No. 144.1-06
File LR-57811
Grade
Residential/Commercial Specification Grade
Trip Level
Class A, 5mA plus or minus 1mA
Body Material
Polycarbonate
Strap Material
Galvanized Steel
Torque Range
14-18 in.-lbs
Line Contacts
Brass Triple-Wipe .031 Thick
Face Material
Thermoplastic
Standards and Certifications
UL/CSA, NEMA WD6, NEMA WD1
Dielectric Voltage
Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Dimensions
4.21 in H x 1.69 in W x 1.4 in D
Terminal Type
Back/Side Wired
Temperature Rating
-35C to +66C °C
Country of Origin (subject to change)
China
