| Promotion Restriction | Not eligible for promotion |
| Item | Hydraulic Electric Pump, Workholding |
| Type | Hydraulic |
| Reservoir Capacity (Cu.-In.) | 462 cu in |
| Reservoir Capacity (Gal.) | 2 gal |
| Oil Displacement @ 100 PSI | 200 cu in/min |
| HP | 0.75 hp |
| Maximum Pressure | 5,000 psi |
| Motor Type | Induction |
| Reservoir Material | Steel |
| Charger Input Voltage | 115V AC |
| Control Pendant Voltage | 24V DC |
| Control Valve | 3-way, 2-position, Dump |
| Voltage | 115V |
| dBA | 71 to 75 dBA |
| Oil Displacement @ 5000 psi | 40 cu in/min |
| Overall Height | 20.4 in |
| Overall Length | 19.3 in |
| Overall Width | 11 in |
| Phase | Single |
| Sound Level - Maximum | 75 dBA |
| Sound Level - Minimum | 71 dBA |
| Cylinder Compatibility | Single Acting |
| Displacement @ 100 psi | 200 cu in/min |
| Flow Rate - Maximum | 40 cu in/min |
| Operating Pressure - Maximum | 5,000 psi |
| Reservoir Capacity | 2 gal |
| Frequency | 50 Hz, 60 Hz |
| Horsepower - Maximum | 3/4 hp |
| Displacement @ 5000 psi | 40 cu in/min |
| Nameplate Voltage | 115V AC |
| Control Valve Function | Advance, Retract |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Hydraulic Electric Pump, Workholding, ENERPAC, Mfr# ZW2108DB
$5276,99
Free shipping will be applied on orders over $50
Hydraulic Electric Pump, Workholding, Horsepower - Maximum 3/4 hp, Nameplate Voltage 115V AC, Phase Single, Operating Pressure - Maximum 5,000 psi, Displacement @ 5000 psi 40 cu in/min, Reservoir Capacity 2 gal, Reservoir Material Steel, Overall Height 20.4 in, Cylinder Compatibility Single Acting, Charger Input Voltage 115V AC, Control Pendant Voltage 24V DC, Control Valve Function Advance, Retract, Displacement @ 100 psi 200 cu in/min, Flow Rate - Maximum 40 cu in/min, Frequency 50 Hz, 60 Hz
0 in stock
Must order in multiples of 1
Subtotal:
$5276.99
