| Property | Value |
|---|---|
| Item | LCR Meter |
| Inductance Range | 4 to 400 micronH; 4 to 400 mH |
| Inductance Accuracy | 0.1% + 2 Digits, 0.3% + 2 Digits, 0.35% + 2 Digits, 0.45% + 2 Digits, 0.5% + 2 Digits, 0.8% + 3 Digits, 0.8% + 5 Digits, 1.4% + 5 Digits, 1.5% + 2 Digits, 1.5% + 5 Digits, 1% + 3 Digits, 2.5% + 10 Digits |
| Display | Dual Backlit Display |
| Capacitance Range | 4 to 400 pF; 4 to 400 nF; 4 to 10 micronF |
| Capacitance Accuracy | 0.1% + 2 Digits, 0.35% + 2 Digits, 0.35% + 3 Digits, 0.5% + 2 Digits, 0.8% + 2 Digits, 0.8% + 5 Digits, 1.25% + 5 Digits, 1.5% + 3 Digits, 1.5% + 5 Digits, 1% + 3 Digits, 2.5% + 10 Digits, 2% + 5 Digits, 3% + 5 Digits, 5% +5 Digits, 6% +20 Digits |
| Includes | (4) Terminal Shielded Kelvin Clip Test Leads (TL8KC1), AC Adapter, Banana-to-Alligator Test Leads, Mini USB Interface Cable, Shorting Plate, SMD Tweezer |
| Resistance Range (Ohms) | 0.4 to 400 ohm; 4 to 20 megaohm; 4 to 400 kiloohm |
| Resistance Accuracy | 0.1% +2 Digits, 0.35% +2 Digits, 1% +3 Digits, 3% +3 Digits, 3% +5 Digits |
| Counts | 10,000 Secondary, 40,000 Primary |
| Audible Continuity | Yes |
| Manufacturers Warranty Length | 3 yr |
| Auto Power Off | Yes |
| Battery Type | 9V |
| Test Frequencies | 100 Hz, 120 Hz, 1,000 Hz, 10 kHz, 100 kHz |
| Interface | USB |
| Product Type | LCR Meter |
| Inductance Measurement - Maximum | 1,000 H |
| Inductance Measurement - Minimum | 4 uH |
| Resistance Measurement - Maximum | 10 megaohm |
| Capacitance Measurement - Maximum | 20 mF |
| Includes Batteries | Batteries Included |
| Resistance Measurement - Minimum | 0.4 ohm |
| Primary Display Counts | 40,000 |
| Number of Batteries Required | 1 |
| Battery Size | 9V |
| Standards | EN61010 (IEC 1010-1) |
| Digital Display Screen Type | LCD with Backlight |
| Capacitance Measurement - Minimum | 4 pF |
| Battery Voltage | 9 V |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
LCR Meter, B&K Precision, Mfr#: 880
$568.99
Free shipping will be applied on orders over $50
LCR Meter, Inductance Range 4 to 400 micronH; 4 to 400 mH, Inductance Accuracy 0.1 Percent + 2 Digits, 0.3 Percent + 2 Digits, 0.35 Percent + 2 Digits, 0.45 Percent + 2 Digits, 0.5 Percent + 2 Digits, 0.8 Percent + 3 Digits, 0.8 Percent + 5 Digits, 1.4 Percent + 5 Digits, 1.5 Percent + 2 Digits, 1.5 Percent + 5 Digits, 1 Percent + 3 Digits, 2.5 Percent + 10 Digits, Capacitance Range 4 to 400 pF; 4 to 400 nF; 4 to 10 micronF
Out of stock
