| Property | Value |
|---|---|
| Item | C-Hook Leveling Pipe Lifter |
| Capacity | 6,000 lb |
| Throat Height | 8 in |
| Min. Pipe Inside Diameter | 10 in |
| Overall Width | 14 in |
| Lifting Arm Length | 53 in |
| Headroom | 35 5/8 in |
| Bail Opening Height | 5 in |
| Bail Center of Gravity | 24 in to 48 in |
| Bail Width | 1 in |
| Standards | ASME |
| Material Above the Bail Opening | 1 1/2 in |
| Bail Opening Width | 3 in |
| Bail Inside Width | 3 in |
| Minimum Headroom | Not Applicable |
| Maximum Load Capacity | 6,000 lb |
| Bail Thickness | 1 in |
| Maximum Headroom | 35 5/8 in |
| Minimum Pipe Diameter | 10 in |
| Bail Inside Length | 5 in |
| Bail Height | 5 in |
| Arm Length | 53 in |
| Arm Height | 6 7/8 in |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Leveling Concrete Pipe Lifter, 6000 Lbs., Caldwell, Mfr#: CPL-3
$5149.99
Free shipping will be applied on orders over $50
C-Hook Leveling Pipe Lifter, Maximum Load Capacity 6,000 lb, Minimum Pipe Diameter 10 in, Minimum Headroom Not Applicable, Maximum Headroom 35 5/8 in, Bail Inside Length 5 in, Bail Inside Width 3 in, Throat Height 8 in, Arm Height 6 7/8 in, Arm Length 53 in, Overall Width 14 in, Bail Height 5 in, Bail Thickness 1 in, Standards ASME
9999 in stock
