Max. Rated Flat Capacity
150 lb
Magnet Activation
Locking On/Off Handle
Max. Heat Resistant Temp.
180 Degrees F
Features
Lifts Flat or Round Loads Horizontally and Flat Loads Vertically, Top Rotating and Locking On/Off Handle
Footnotes
Lifting Magnets are Stated At 33% of The Maximum Lifting Value, When Lifting Sheets Plates Over (8) Feet Long, Use Two or Magnets On A Spreader Beam to Prevent Sheets From Flexing, Sagging or Peel Off, Thin Material Is Susceptible to Magnetic Bleed Through, Resulting In Two Sheets Being Lifted At Once, Round Item Lifting Values are Based on Ideal Conditions, Length, Wall Thickness, Diameter and Surface Condition Can All Effect The Magnets Performance
Magnet Material
Rare Earth
Required Material Thickness for Max Rated Capacity
3 in
Standards
ASME B30.20 BTH-1
Min. Material Thickness for Activation
1/4 in
Bail Opening Height
2 1/4 in
Max. Rated Capacity @ Min. Activation Thickness
150 lb
Max. Rated Round Capacity
75 lb
Minimum Thickness for Maximum Load Capacity
3 in
Maximum Round Load Capacity
75 lb
Activation Mechanism
On/Off Handle
Minimum Operating Temperature
-10 Degrees F
Minimum Thickness for Activation
1/4 in
Bail Inside Length
2 1/4 in
Maximum Operating Temperature
180 Degrees F
Maximum Flat Load Capacity
150 lb
Maximum Load Capacity
150 lb
Country of Origin (subject to change)
Multiple
