Temp. Range
Upto 180 Degrees F
Height to Top of Heater
71 13/16 in
Recovery @ 70 F Rise
277 gph
Standards
AHRI Certified, Canada CSA, LWH, UL Listed, US CSA (Star)
Tank Capacity - Plumbing
91.0 gal
Recovery @ 100 F Rise
194 gph
Recovery @ 130 F Rise
149 gph
BtuH - Water Heaters
199,900
Recovery @ 140 F Rise
138 gph
Includes
Brass Drain Valve and Factory Installed T and P Valve
Recovery @ 120 F Rise
162 gph
Recovery @ 110 F Rise
176 gph
Fuel Type - Water Heaters
Liquid Propane
Manufacturers Warranty Length
Limited 3 yr Tank and 1 yr Parts
First Hour Recovery - Water Heaters
258 gph
Overall Height - Water Heaters
76 5/16 in
Recovery @ 50 F Rise
388 gph
Item - Water Heaters
Gas Water Heater
Commercial / Residential
Commercial
Item
Commercial Gas Water Heater
First Hour Recovery
258 gph
Side Water Connection Size
1 1/2 in
Features
Full Port/Full Flow Drain Valve, Patented Anode Rods, Stainless Steel Burners, LED Diagnostic System
Height to Gas Connection
7 in
Top Water Connection Size
1 1/2 in
Height to Cold Side Connection
30 5/8 in
Ignition Type
Direct Spark to Pilot
Residential / Commercial
Commercial
Height to Hot Side Connection
66 3/8 in
Recovery @ 90 F Rise
215.0 gph
Height to Top of Vent Connection
76-5/16
Height to T and P Valve
66.37 in
Overall Dimensions - Ht. x Dia.
76.31 in x 26.25 in
Maximum Delivered Temperature
180 Degrees F
Height to Cold Inlet
30.62 in
Included Valve Type
T u0026 P Relief
Minimum Delivered Temperature
100 Degrees F
Water Connection Location
Front, Rear, Top
Included Valves
Temperature and Pressure Relief
Recovery Rate @ Rise
138 gph @ 140 Degrees F, 149 gph @ 130 Degrees F, 162 gph @ 120 Degrees F, 176 gph @ 110 Degrees F, 194 gph @ 100 Degrees F, 215 gph @ 90 Degrees F, 242 gph @ 80 Degrees F, 277 gph @ 70 Degrees F, 323 gph @ 60 Degrees F, 388 gph @ 50 Degrees F, 485 gph @ 40 Degrees F
Maximum Heating Capacity
199,900 BTU/ft/sq ft/hr/ Degrees F
Manufacturer Warranty Length
3 yr Limited Tank
Tank Insulation Material
Fiberglass
Height to Hot Outlet
66.37 in
Vent Configuration
Standard Atmospheric
Maximum Recovery Flow Rate
485 gph @ 40 Degrees F
Maximum Water Pressure
150 psi
Nominal Tank Capacity
90 gal
Low NOx Compliant
Includes Standard Burner
Country of Origin (subject to change)
United States
