Item
Low Pressure Gas Test Kit
Range
0 to 15 in wc, 8 oz/sq in
Pressure Range
0 to 15 in wc
Temperature Range (F)
-40 Degrees to 150 Degrees
Includes
Gauge, Gear Clamp, Hose Tube, Tube Nipple
Manufacturers Warranty Length
5 yr
Connection Size
1/4 in Hose Barb
Application
Gas Measurement
Gauge Primary Range Values
0 to 15
Calibration Certificate Included
No
Gauge Connection Type
MNPT
Gauge Connection Location
Bottom
Gauge Special Options
Diaphragm
Gauge Nominal Dial Size
2 1/2 in
Gauge Lens Material
Polycarbonate
Connection Location
Bottom
Gauge Secondary Range Values
0 to 70,000
Gauge Primary Range Units
in wc
For Use With
Media Compatible with Bronze
Gauge Connection Size
1/4 in
Gauge Socket Material
Brass
Operating Temp. Range
-40 Degrees to 150 Degrees F
Gauge Secondary Range Units
gpm
Gauge Sensor Material
Brass
Process Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Process Connection Size
1/4 in
Temperature Scale Units
Degrees C, Degrees F
Primary Pressure Range
0 to 15
Secondary Pressure Range
0 to 8
Process Connection
1/4 in Hose Barb
Process Connection Type
Hose Barb
Process Connection Location
Bottom
Dial Face Material
Aluminum
Pressure Gauge Type
Gas Line Pressure Test Kit
Nominal Dial Size
2 1/2 in
Pressure Gauge or Kit Type
Low Pressure Gas Line Test Kit
Accuracy Grade
ASME B40.100 Grade B
Primary Pressure Scale Color
Black
Sensor Material
Phosphor Bronze
Freeze Resistant Movement
No
Pressure Range Type
Pressure
Lens Material
Polycarbonate
Secondary Scale Units
oz/in2
Compatible Process Media
Gas
Manufacturer Warranty Length
5 yr
Secondary Pressure Scale Color
Red
Country of Origin (subject to change)
China
