| Item | Mechanical Connector |
| Connector Type | Compact |
| No. of Conductors | 1 |
| Min. Conductor Size | 14 AWG Solid |
| Max. Conductor Size | 8 AWG Stranded |
| Stud Size | 13/64 in |
| Material | Electrolytic Copper |
| Length | 0.81 in |
| Width | 0.38 in |
| Head Style | Slotted |
| No. of Holes | 1 |
| Standards | UL Listed, UL486A/B |
| Screw Material | Steel |
| Body Material | Copper |
| Length (Straight Wireway) | 0.81 in |
| Connection Orientation | Compact |
| Tongue Length | 0.5 in |
| Screw Finish | Zinc Plated |
| Hole Spacing | Not Applicable |
| Number of Terminations | 1 |
| For Stranded Copper Wire Size - Maximum | 8 AWG |
| Wire Size Ranges | 14 AWG - 8 AWG |
| UL Standard | UL 486A-486B |
| Tongue Width | 0.38 in |
| Overall Depth | 3/8 in |
| Special Features | Cold Forged from Pure Electrolytic Copper With 99 Percent Conductivity |
| Maximum Voltage | 1,000 V |
| For Wire Size | 12 AWG, 14 AWG, 8 AWG |
| Hole Diameter | 0.2 in |
| For Stranded Copper Wire Size - Minimum | 14 AWG |
| Overall Length | 0.81 in |
| Number of Conductors | 1 |
| For Stud Size | 13/64 in |
| Tongue Thickness | 0.09 in |
| Maximum Operating Temperature | 194 Degrees F |
| Overall Width | 0.38 in |
| For Conductor Material | Copper |
| Type | Copper Connectors |
| Features | Cold forged from pure electrolytic copper with 99 percent conductivity. |
| Standard | UL E9809 |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Mechanicl Conn, Cmpact, 8 to 14 AWG, 1 Cond, BLACKBURN, Mfr# L35
$1,49
-3% / ea
with subscription
Free shipping will be applied on orders over $50
Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 14 AWG, For Stranded Copper Wire Size - Maximum 8 AWG, For Stud Size 13/64 in, Head Style Slotted, Number of Holes 1, Hole Diameter 0.2 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 1,000 V, Number of Conductors 1, Number of Terminations 1, Tongue Length 0.5 in, Tongue Width 0.38 in, Tongue Thickness 0.09 in, Connector Type Compact
